AUDIO 64 IN 64 OUT MATRIX
GF-AUDIO6464

Guangzhou Gefen GF-AUDIO6464 is a matrix switcher that supports 64/632/16 audio signal input and 64/32/16 audio and video signal output. The input 64/32 stereo audio signal can be switched synchronously or asynchronously to either or more channel outputs. High-performance audio processing and signal long-distance transmission distortion gain compensation technology are used to enable audio signals to transmit high-fidelity output over long distances.

It has RS-232 communication interface, which is convenient to connect with computers, remote control systems or various remote control devices.

Detail

● Support 64/32/16 audio signal input, 64/32/16 audio signal output.

●The input and output terminals of audio signals adopt 5-bit 3.8mm phoenix interface.

● Support fast switching operation.

●Programmable logic display circuit is adopted, and any interaction is switched.

●Support audio and video synchronization or separation switching function.

● Support channel switching permission setting, audio and video channel switching permission can be managed separately and independently.

●Audio signal types are: stereo (balanced or unbalanced connection).

●The volume of each audio output channel can be adjusted independently.

●It has the function of power-off memory and the on-site protection function of power-off.

●It has 2 RS-232 communication interfaces.

● Built-in international power supply.

● Standard 19-inch cabinet mounting: 2U metal chassis.
