KVM network HDMI with HDB

HDMI2.0 single network cable extender transmits high-definition video signals over long distances through a single unshielded CAT-6 network cable, which can transmit HDMI2.0 4K@60Hz signals up to 60M or 4K@30Hz and 1080P@60Hz video signals up to 100M, and the accompanying KVM function and infrared backhaul function make long-distance control more convenient. The equipment has excellent image processing and transmission capabilities, making the signal transmission more smooth and stable, and is a reliable, high-performance, and efficient HDMI signal extension method, which is widely used in video conferencing, multimedia teaching, securities and finance, office and other fields.

●Support HDMI2.0, HDCP2.2

●Support to extend the 2K*4k@60Hz resolution audio and video signal by 60 meters, 2K*4k@30Hz or 1920*1080p@60Hz resolution audio and video signal by 100 meters

● The resolution supports up to 2k*4k@60Hz YUV4:4:4 and GRB4:4:4 formats

●Support HDR10EDID transparent transmission, which can adapt to more application environments

●Support 20~60KHz broadband infrared backhaul function

●Support KVM function, can use mouse and keyboard to control the computer host at the remote end

●The network cable adopts the standard Ethernet IEEE-568B connection, which is easy to install

●Built-in automatic equalization system, the picture is smooth, clear and stable

●Built-in ESD electrostatic protection circuit, peripheral ground wire interface, all-round protection system safety

●Support plug and play, no need to install driver, no setting, simple and convenient installation

HDMI version: HDMI 2.0

HDCP version: HDCP 2.2

EDID Function: Yes

HDMI video bandwidth: 600MHz

HDMI video rate: 18Gbps

HDMI Video Color Depth: 4K60P: (420/422) 8,10 vs 12Bit / 4K60P: (444/RGB) 8Bit

HDMI input/output: 3840*2160@60Hz, 3840*2160@30Hz, 1920*1080p@60Hz, 720p

Audio format: DTS/Dolby/LPCM

Input video signal: 0.5~1.5Volts p-p

Output DDC signal: 5Volts p-p(TTL)

Input/output cable length: ≤10m AWG26 HDMI2.0 standard cable

Maximum operating current: 350mA

Power supply: DC 5V/1A

Shell Material: Iron Shell

Network cable requirements: CAT-6 standard network cable

Transmission distance: 2k*4k@60Hz YUV444 extension 60m/2k*4k@30Hz or 1920*1080p@60Hz extension of 100m

Transmission distance................................................ CAT6-60M (4K@60Hz YUV444) or CAT6-100M (4K@30Hz and 1080P@60Hz),
HDMI Input/Output ............................................. 3840*2160@60/30/1080P/720P
Audio Format............................................. DTS/Dolby/LPCM
HDMI version............................................. HDMl2.0HDCP2.2/Adaptive EDID
HDMI video bandwidth, rate Bandwidth: 600MHz / Rate: 18Gbps
HDMI Video Color Depth ............................................. 4K60P: (420/422) 8,10 and 12 Bits4K60P: (444/RGB) 8 Bits
Input video signal ............................................. 0.5~l.SVolts p-p
Output DDC signal............................................. SVoltsp-p(TTL)
The input and output lines are ............................................. long; 10MAWG26 HDMl2.0 standard cable
Maximum operating current............................................. 350mA
Power adapter AC input............................................. (50-60HZ) 100V-240V, direct output: SV/lA
