4-channel SDI intelligent high-definition conferen
GF-RBT01

GEFFEN Smart Conference Series GF-RT4000 is an integrated recording and broadcasting device that integrates courseware recording, live broadcast, on-demand, intelligent director, storage and other functions, based on embedded hardware architecture design, and the product is highly stable. The device supports audio and video collection and recording of 5 scenes (teacher panorama, teacher close-up, student panorama, student close-up, computer signal), and cooperates with the tracking system to achieve automatic tracking and broadcasting. The device supports simultaneous recording and live streaming in movie mode + resource mode, and the screen supports 1/2/3/4//6 split screen, picture-in-picture mode display and recording. The recording and broadcasting host is equipped with a recording and broadcasting touch screen, allowing users to operate more flexibly and quickly. Combined with the educational recording and broadcasting system, resource management platform, and director and tour platform, the application requirements of various scenarios can be realized.

● Embedded Linux system
● Support single screen, picture-in-picture, picture-over-picture, 2/3/4/6 split screen
● The device supports audio and video capture and recording of 5 scenes (teacher panorama, teacher close-up, student panorama, student close-up, computer signal).
● Cooperate with the tracking system to achieve automatic tracking and broadcasting
● Maximum input resolution 1080P@60fps
● Standard 1T hard disk, support expansion
● Support network upgrade and RS232 serial port upgrade
● Standard RTMP protocol, RTSP real-time protocol stream, UDP multicast stream, TCP unicast stream
