Configure the installation |
No configuration, no installation |
|
|
interface |
Type-C/HDMI/USB Device |
|
|
System types are supported |
Windows、Mac、Linux |
|
|
resolution |
USB (1080P), HDMI/Type-C (4K-30Hz point-to-point) |
|
|
Frame rate |
30~60frame |
|
|
Overall latency |
90~180ms |
|
|
Transmission distance |
30m unobstructed |
|
|
Display mode |
Extended desktops are supported（Windows、Mac、Linux） |
|
|
Touch the counter-control |
Support 10-point touch callback（Windows、Mac、Linux） |
|
|
Mouse mode callbacks are supported（Windows、Mac、Linux） |
||
|
Number of connections |
1~8(If more than 8 channels are required, additional engineering routers need to be configured) |
|
|
The maximum number of simultaneous display channels |
4 screens |
|
|
Wireless rate |
300Mbps on the transmitter |
|
|
Wireless transmission protocol |
IEEE 802.11 a/g/n/ac |
|
|
Band |
5.8G，Multi-channel selection |
|
|
Verify the protocol |
WPA2-PSK |
|
|
Upgrade method |
Host USB upgrade screen passer |
|
|
Meeting mode |
Moderator mode |
The host can touch the screen list to select a specific PC to transfer the screen |
|
Participant mode |
The last device to tap the cast screen gets control of the screen transfer |
|
|
USB |
3 |
HDMI output |
1 x 4K 60Hz |
|
Memory size |
2G DDR3 |
Storage space |
8G |
|
HDMI input |
1 |
TF Extension |
Up to 64G |
|
Wired network port |
1 |
Infrared remote control |
1 |
|
audio |
3.5mm audio |
Phoenix interface |
RS232*2 |
|
SoftAP |
5.8G （WiFi6） |
Wifi |
5.8G |
|
Rotation mode |
Support 90 degrees, 180 degrees, 270 degrees screen rotation |
|
One-time password |
AirPlay, Miracast, BZCast screen transfer client software supports dynamic password protection |
|
Write annotations |
Single-point writing, multi-point roaming zoom, gesture erasing, support QR code scanning and sharing |
|
Video output |
1 HDMI output |
|
Real-time clock |
Built-in coin cell battery, power down can maintain normal operation for time |
|
Restart at a scheduled time |
It supports the timed restart function to ensure the healthy operation of the device all year round |
|
Other small apps |
Welcome message, file browser with classification function, screensaver |
|
Camera and microphone |
Wirelessly share camera and microphone |
|
Four screens |
Four-screen 1080P point-to-point display |
|
Wired projection |
Support HDMI input + USB wired screen projection |
|
Broadcast control |
Remotely control audio and video playback |
|
Centralized control |
Unified management of devices in batches |
|
Web projection |
Share the web interface over a public network |
|
Hybrid projection |
Support Miracast and Airplay hybrid projection |
|
Router mode |
Support both 2.4G and 5.8G APs for screen transfer (optional) |
|
Chrome Mirroring |
Support Chrome web screen mirroring |
