● Support 1 VGA, 2 DP, 4 HDMI (including 3 MHL compatible) signal input, DP input resolution up to 3840*2160@60Hz, backward compatible, HDMI input resolution up to 3840*2160@30Hz, backward compatible, VGA input resolution up to 1920*1200@60Hz, backward compatible.
● Support 1 HDMI2.0 output, the output resolution can reach up to 3840*2160@60Hz.
● Support point-to-point simultaneous display of 4 channels of full HD 1920*1080 signal.
● The input and output signals all support audio, and at the same time support 3.5mm left and right channel stereo output.
● 2 USB signal output, USB supports connecting mouse and keyboard, image and USB synchronous switching.
● Display 4 high-definition digital/analog signals on a single screen at the same time, or switch signals to display a signal on a full screen.
● Support image fixed position POP, PIP function.
● Support 100V~240V ultra-wide AC voltage input, which can be used in any country in the world.
● Standard 19-inch 1U brushed chassis, which can be directly mounted on the standard cabinet.
● Support chassis button, infrared remote control, RS-232 serial port control and central control.
●Pure hardware architecture
Pure hardware architecture, no CPU, no memory, only need 3 to 5 clocks to boot, the system is stable, no risk of crash, virus infection, system crash, can work 24 hours a day, 365 days a year;
●Advanced DSP image processing technology
It adopts the most powerful image processing chip DSP technology at present. DSP technology supports a variety of world-leading image processing technologies and functions, such as DCDI edge smoothing, ACM color adaptive management, CCS bright color crosstalk suppression, SHARPNESS sharpness enhancement, dynamic contrast enhancement, true six-axis color control overlap, noise cancellation and amplification.
And it has advanced features such as de-interlacing technology with 3D comb filtering video decoding, 3D noise reduction and motion adaptive compensation, skin tone correction, color vibrancy enhancement, GAMMA correction and frame rate conversion. The output picture is free of aliasing and smearing, and the picture quality is delicate and sharp, clear and smooth, and the color is bright.
●Powerful data computing ability
The data adopts parallel processing technology, the output port occupies one channel, the data bandwidth of each channel reaches 10.2G/s, and the output reaches 3840*2160@60Hz high-resolution display. There is no tailing, delay, tearing, frame loss, and image catch-up in high-speed dynamic images.
●Support 3840*2160 high-definition signal input and output
It supports the input of 1 VGA, 2 DP and 4 HDMI signals, and HD video supports interlaced and progressive input. The product supports up to 3840*2160@60Hz ultra-high-resolution signal input, and is backward compatible, all input signals through professional-grade image processing chips, unified output progressive 60Hz HDMI signal, the highest output resolution supports 3840X2160@60Hz, and users can choose other resolutions according to their needs, such as 1920*1080@60Hz, 2560x1440@60Hz, 3840X2160@30Hz.
●USB switching function
It supports the function of switching between USB and screen at the same time, which perfectly solves the problem that the previous product cannot synchronize the video image with the USB connected device (such as USB mouse, keyboard, etc.).
●Ultra-low power consumption
The product adopts low-power consumption design, the actual power is only about 10W in the working state, no fan heat dissipation, energy saving and environmental protection, no noise pollution, and is suitable for all kinds of meetings or other places with strict noise control.
● Multiple display modes
In addition to quad split display and single screen full display, it can also support a variety of different display modes.
