GF-MPP
The GEFFEN MPP series processing equipment adopts a pure hardware architecture to fully ensure the security of the system, and carries management and control information through a dedicated physical channel. The backplane switching architecture has a bandwidth of 10Gbps for a single output channel, with each output channel independent of each other. Modular plug-in card design, input card, output card, switch card, control card, power supply, etc. all adopt modular design, which is convenient for future system upgrade and maintenance.

Product features
Geffen GEFFEN Window Roaming Overlay Matrix strengthens the signal processing system and is a new device developed for the coexistence of analog and digital signals, as well as the coexistence of high-definition signals and standard definition signals. Analog and digital signals can be processed centrally and converted into a uniform format output. It is possible to switch the input signals in a variety of different formats intuitively, easily and conveniently.
The window roaming superposition matrix strengthens the signal processing system with modular design, plug-in card structure, supports hot swapping, can be combined at will, which is convenient for customers to select, and for different use needs, the capacity is selected from 4x4 to 72x72.

Features:
●Modular design, plug-in card structure, can be freely combined and assembled according to the actual situation;
●The input signal supports DVI, HDMI, VGA, HD-SDI, HDBaseT, 4K, Video and IP stream decoding, etc.
●The output signal supports DVI-I, HDMI, RJ45 and HDBaseT formats;
●Signal processing and switching are fully digital, support signal format conversion, and support frequency doubling and multiplier conversion functions;
●The video input of the high-definition digital image processing system can realize the display of 4 split screens;
●Support input signal status monitoring, which can monitor and display whether the current input channel is valid signal access in real time;
●It has the function of power-off memory, with on-site protection of power-off, forced air cooling, to ensure the stable operation of the system;
●The use of proprietary control software can be remotely controlled through Ethernet and RS232, supporting multi-channel switching, address setting and other functions.

Applications
Command and Control Center
Large multimedia conference hall
Multimedia classrooms
Superior villas, hotels
Smart home security monitoring system
Digital city systems






●Adopt B/S architecture, no need to install apps to achieve Windows, iOS, Android cross-platform control.
●Any mixed combination of boards, DVI, HDMI, VGA, SDI, DP, IP supports any two interfaces to be freely combined, strong equipment scalability, various use scenarios, online status monitoring of sub-cards, improves the flexibility of system design and operation during transformation and upgrading, flexible combination, simple maintenance, and can effectively reduce the equipment failure rate.
●Support DVI-I, HDMI, SDI, HDbaseT and other signal outputs.
●Seamless mixing between 4K and below resolution signals:
●There is no black field, no blue screen, no intermediate transition state for signal switching, and the signal display is not interrupted.
●Support cloud application function, cloud encoding mode is carried out on multiple application software interfaces on the computer, and decoded by the processor cloud application board, so that multiple application contents of the same computer application software can be shared and displayed at the same time.
●Support visual operation, realize the preview echo function, real-time monitoring of the signal source screen, support the addition of multiple preview cards to achieve more signal preview. It supports visual operation, realizes the preview echo function, monitors the signal source screen in real time, and supports adding multiple preview cards to achieve more signal forecasting.
●Support product status monitoring, input board, output board, power supply, control card operation status and temperature monitoring, management personnel can understand the operation of the equipment in real time.
●Image frame synchronization processing is adopted to ensure the synchronization of all output images. Ability to keep the refresh of the video consistent with the external video source,
●Support real-time synchronous playback of video of any size and resolution, support any channel output, and the synchronization time of each channel output is less than 20 milliseconds.
●Relying on TT scaler algorithm, stepless scaling is used to ensure that the aliasing phenomenon is relatively small when shrinking, the image processing effect is excellent, and the phase filter processing technology is used to compress and filter the frequency band of the image, the image stacking is greatly reduced, the image edge is clearly visible, and the color reproduction is high. Any signal can be scaled in any proportion, and by using multi-bit phase filtering technology, the physical boundary of the scaled image can be kept clear and natural, and the color depth of the texture is consistent with the original image.
●The input and output sub-cards support hot-swap function, and the device does not need to be shut down, and the previous layer data can be quickly restored after replacing the sub-card to ensure the normal playback of the picture
●Support signal source cropping, in order to remove the black edge of the signal source or realize the magnification of the key area of the image, support input pixels for precise cropping, can also support mouse drag and drop for visual cropping,
●Support multi-device encryption authorization function, and centrally control the device through encryption settings to ensure the safety of user operation
●Support frame multiplication function, which can convert the input signal from 30Hz to 60Hz signal output
★LCD touch interface is optional.
★ It supports real-time preview of the matrix monitoring screen, reduces the operation error rate, and makes the matrix operation more flexible and intuitive.
●1-channel RJ45 interface preview output, which can view 4-channel video image information in groups at the same time;
●The resolution of each video reaches 1080P@30fps or 720P@30/60fps;
★ H.264&JPEG multi-stream encoding, frame rate supports 1/16~60fps;
●Support hot-swappable;
★ Support preview control video switching.

Support Signals:

VGA (RGB) input
Connector 15-pin D-sub(DB15/DE-15F)(Female)
Resolution: 1920x1080 or less, adaptive, refresh rate of 60Hz;
DVI-D input
Connector DVI: 24+5-pin/DVI-I/Female (DVI-D signal only)
Resolution: 1920x1080 or less, adaptive refresh rate of 60Hz;
Video video input
Connector Composite Video: BNC (Female);
Type: PAL format;
SDI video input
Protocols SD-SDI (SMPTE 259M), HD-SDI (SMPTE 292M) and 3GSDI are supported
Connector BNC (female);
HDMI signal input
Resolution 1920x1080 or less self-adaptive;
Connector HDMI Type A, HDCP 1.3;
HDBaseT signal input
Connector RJ45 network interface, cable length support 70 meters (100 meters), support cat5e, cat6;
Resolution: 1920x1080 or less, adaptive refresh rate of 60Hz;
4K signal input
Connector HDMI Type A, HDMI 1.4 / DVI 1.0;
Resolution: 3840x2160@30Hz, adaptive below 1920x1080, refresh rate of 60Hz;
IP stream decoding signal input
Connector RJ45 network interface
Protocol H.264/RTSP/RTP
Resolution: 4-way 1080P@30
Subtitle signal input
Interface: No interface
Number of available 2 scrolling subtitles
Audio signal input
Interface: 3.5 audio port
DVI/VGA output
Interface: 24+5-pin DVI-I (female, convertible to VGA, RGB);
The resolution can be set below 1920x1080, and the refresh rate is 60Hz;
Twisted pair output
Interface: RJ45 network interface, support cat5e, cat6, support 15~50 meters;
The resolution can be set below 1920x1080, and the refresh rate is 60Hz;
HDMI output
Interface: HDMI Type A (female);
The resolution can be set below 1920x1080, and the refresh rate is 60Hz;
SDI output
Interface BNC (female), support SD/HD-SDI/3G SDI;
The resolution can be set below 1920x1080, and the refresh rate is 60Hz;
HDBaseT output
Connector RJ45 network interface, cable length support 70 meters (100 meters), support cat5e, cat6;
Resolution: 1920x1080 or less, adaptive refresh rate of 60Hz;
Audio signal output
Interface: 3.5 audio port

Software application features:

The window roaming overlay matrix strengthens the signal processing system software is oriented to the processing system equipment, which can realize the control operation and automatic monitoring function of the window roaming overlay matrix to strengthen the signal processing system, and the user can realize the control function of the control system of the signal processing system on the window roaming overlay matrix, and at the same time can realize the intelligent monitoring function of the relevant peripheral equipment, and can realize the function of automatically switching the system mode.
Device search, connection, and configuration
Configure the parameters of the software to connect to the device, search for the device, obtain the device information, and splice the settings.
Windowing & Editing
Through the window opening and editing function, you can control the position and size of the display window on the output screen and edit the function, and at the same time, you can edit the layer of the window, and provide some one-click operation functions to delete and put in the minimum.
Plan management and patrol rotation
Realize the saving and management functions of the plan, including saving the plan file, opening the plan file, and calling the setting and control of the plan and the plan patrol.
