IOT programmable control system
GF-MAXCC

GEFFEN IOT series is equipped with Cortex-M4+Cortex-M3®® dual-core processing chip, built-in low-power, high-performance DAC audio processing module, equipped with 1.14-inch full-color high-definition IPS LCD display, 10/100M dual-channel network interface, supports standard POE power supply IEEE 802.3af standard, and the system provides control indicators for each signal interface, which can dynamically monitor the working status of each signal interface.

Detail

◆Audio input and output port x1
It supports a digital audio signal input port for digital audio processing, supports bass enhancement, treble, EQ, etc., and then outputs 24-bit stereo sound

◆IR receiver port x1
GF systems have an infrared receiver port that can receive infrared signals for infrared Xi functions

◆IR emitter x4
It provides four independent infrared emission interfaces, which can be connected to multiple infrared devices
Small signal relay control interface x4
Provide 4 independent small signal relay control interfaces, easy to expand

◆ Digital I/O port x4
It has four independent digital control I/O ports

◆ RS_485 x1
Support one RS_485 signal interface

◆ RS_422 x1
Support one RS_422 signal interface

◆ RS_232 x5
Supports up to 5 independent 3-wire (RXD, TXD, GND) serial RS_232 signal interfaces

◆ . RS_232 with RTS, CTS x1
RS-232 interface for hardware control flow RTS, CTS handshake function

◆ TYPE C USB port x1
The universal TYPE C USB interface can be used for system upgrades

◆ 24V fire signal monitoring interface x1
Provide 24V fire signal monitoring interface, convenient for the application of fire monitoring

◆ POE power supply
Support one standard POE power supply IEEE 802.3af compliant, the maximum output power is 15.4W

◆ 10/100M dual-channel network interface
2 x 10/100base-T(X) adaptive Ethernet RJ45 interfaces
