GEFFEN USB wireless screen projection, up to 30M transmission without obstruction. Support extended desktop, support 4K transmission.
●Support Miracast, iOS, Windows, Mac mixed casting, all devices do not need to download APP, with the built-in wireless projection can be multi-screen projection.
● Dual WiFi modules, you can surf the Internet while projecting the screen.
● Support 4K output.
●Support dual screen.
●Support transmission and power supply through USB port at the same time, and wirelessly transfer the screen to the receiving end.
● Support Miracast screen projection for Android phones and WiDi screen projection for laptops.
●Support plugging in the U disk to play 1080P high-definition lossless film source, to achieve automatic carousel.
● Support the touch control of the transmission computer.
|
Windows software image transfer |
||||
|
Configure the installation |
On the same LAN, no installation of green software is required |
|||
|
System types are supported |
Windows 7/8/10 |
|||
|
resolution |
3840*2160、1920×1200、1920×1080、1280×800、1280×720、1024×768、800×600 720×480 |
|||
|
Frame rate |
30~60 frames |
|||
|
Overall latency |
90~180ms |
|||
|
Display mode |
Extended desktops are supported |
|||
|
Number of connections |
1～8 |
|||
|
The maximum number of simultaneous display channels |
Dual screen |
|||
|
USB wireless screen transfer |
||||
|
Configure the installation |
No configuration, no installation |
|||
|
interface |
USB Device |
|||
|
System types are supported |
Windows 7/8/10,Apple Mac |
|||
|
resolution |
480P~1080P |
|||
|
Frame rate |
30~60 frames |
|||
|
Overall latency |
90~180ms |
|||
|
Transmission distance |
30m unobstructed |
|||
|
Display mode |
Support Extended Desktop (Windows 7/8/10) |
|||
|
Number of connections |
1~8 |
|||
|
The maximum number of simultaneous display channels |
Dual screen |
|||
|
Wireless rate |
Transmitter 300Mbps |
|||
|
Wireless transmission protocol |
IEEE 802.11 a/g/n/ac |
|||
|
Band |
5.8G |
|||
|
Verify the protocol |
WPA2-PSK |
|||
|
Video/Audio |
||||
|
Video decoding |
H.265,H.264,VP8,RV,WMV,AVS,H.263,MPEG4 |
|||
|
Audio decoding |
MP3、WMA、AAC、WAV、OGG、REAL |
|||
|
Image |
JPEG、BMP、GIF、PNG、TIFF |
|||
|
operating system |
||||
|
System version |
Linux 3.10 |
USB pairing interface |
2 |
|
|
central processing unit |
ARM Cortex A7 x 2 |
HDMI output |
1 |
|
|
Memory size |
512MDDR3 |
VGA output |
not |
|
|
Storage space |
128M |
TF Extension |
not |
|
|
Wired network |
RJ45 |
Infrared remote control |
Not supported |
|
|
SoftAP |
802.11AC 5.8G |
Wifi |
2.4G/5.8G |
|
|
HDMI output |
||||
|
resolution |
Max 3840 x 2160 30Hz |
|||
|
USB power supply |
||||
|
input |
DC：12V |
Maximum power |
12W |
|
|
other |
||||
|
Environmental conditions |
Operating temperature |
-10~40℃ |
|
|
|
Operating humidity |
10%-90% |
|
|
|
