1、Support straight-through EDID mode, plug and play, adaptive resolution.

*、Support learning EDID function, one-click learning display EDID.

*、Support built-in 1080P EDID function, one-click to set 1080p.

*、Memory is stored and the last working mode is enabled at boot, saving the trouble of setting.

2、Bidirectional RS-232 extension, serial interface data flows in both directions, allowing remote communication between devices.

3、High-performance digital chip, true restoration of video signals, support uncompressed digital audio transmission.

4、HCDP function: pass-through EDID mode, HDCP 1.x and HDCP2.2 compatible, high-bandwidth digital content protection technology, HDMI uncompressed audio synchronization, EDID signal pass-through from the display to the signal source.

5、10.2GB transmission bandwidth to transmit high-quality audio and video signals.

6、IR Bidirectional Expansion: IR interface data flows in both directions, allowing remote control of peripherals located at both ends of the expansion line.

7、Input power supply: DC12V.

8、It supports PoC power supply, and the product can work when it is connected to TX and RX after being connected through a network cable.

9、Overcurrent protection: Fuses are set at both the power interface and the PoC end to prevent short circuit or high current and protect the safe operation of the device.

10、Support hot-swappable, no need to install drivers, plug and play.

11、Working status prompt: with power light, work light, connection light, signal light, check the working status at any time, convenient troubleshooting.
