DVI 1 point 16 splitter
HDD-1:16 splitter

Geffen Electronics' HDD-1:16 DVI splitter is a multi-port digital video output with one DVI video input and 16 DVI video outputs. Support automatic EDID, in multimedia application systems, often need multiple digital display terminals to display the picture of the same DVI signal source. If a DVI source is configured for each display terminal, this not only increases the system cost, but also greatly reduces the reliability of the system. The DVI distributors from Geffen Electronics are designed to solve these engineering problems. The DVI splitter supports one DVI signal input and multiple DVI signal outputs. This device works with a DVI switcher and can also implement a switching/distribution function.

Detail
Specification

Support DVI-D signal

With EDID Manager (EDID Minder) to automatically manage EDID communication between connected devices.

It has good performance of broadband, high speed, high precision, high output current, low noise and low power consumption.
Support load connection indication.
Ordinary DVI cable not less than 15m can be driven @1920×1200×60.
Use special driver chip to support long-term transmission.
There is an input signal indication.

DVI distribution amplifier with EDID Minder supports 1 input and 8 output, • Supports single-link DVI-D signals with resolutions up to 1920x1200 (including HDTV 1080p/60) • EDID Minder automatically manages EDID communication between connected devices • Automatic input equalization up to 30 meters at 1920x1200/8-bit color with original cable.

Basic bandwidth: 1.6GMhz (-3db) full load Timing standard: Meets the DVI1.0 standard specified by DDWG Coupling mode: 0.05o (RL=150Ω) Differential gain: 0.05% (RL=150Ω) Maximum propagation delay: 5ns(±1) Switching speed≤180nsVideo Signal input------- Signal type: DVI-D interface: DVI-D Interface: DVI-D The highest resolution is 1920×1200×60, compatible with HDMI 1080P standard Timing standard meets the DVI1.0 standard specified by the DDWG organization Connector type: DVI-I (DVI-D signal only) Receiving distance<7m@1920× 1200×60 Signal output------- Signal type: DVI-D digital video signal Interface: DVI-D (only DVI-D signal is supported) Specification Power supply: AC180V~AC240V 50Hz, International Adaptive Power Supply: Power≤10W Operating temperature: 0°C~40°C Storage temperature: -20°CC～85°C.
