Using power sequencer, access to different switch sockets, you can realize from the pre-stage equipment to the post-level equipment, start the power supply one by one, and turn off the power supply on the contrary, effectively and uniformly manage and control all kinds of electrical equipment, avoid human error operation, reduce the instantaneous impact of the electrical equipment switch on the power supply grid, and ensure the stability of the power system. It is widely used in automatic control, TV broadcasting system, audio broadcasting, power facilities and other systems.
●The whole machine is equipped with air switch and voltmeter. The design capacity is 10KVA. Large terminal block access, with protective cover. Ensure the power supply security of the system.
●12-way power sequencing control, each output AC220V (10A) adopts universal socket, suitable for various types of plugs. Reliable key lock control, fingerprint lock control.
●Standard external control interface: 5-24DCV level control and short circuit control mode. It can be connected to an off-site control switch.
●The connection can be extended to form a multi-machine system cascade control. In this control mode, the first unit is turned on, and each power sequencer is started step by step.
● Standby power switch: It can be used to prevent the controller from losing control for some reason, turn off this switch, and all outlets can be connected at the same time.
●GF-PMP12H provides full power regulation characteristics. It provides spike suppression and surge voltage protection between 3 phases (fire to zero, fire to ground and zero to ground). A special 40amp multi-stage EMI filter is used to purify the system power. Interference signals from devices such as fluorescent lamps, dimmers or wireless transmitters can leak through AC power to audio and video
frequency or control system. The filter can greatly eliminate the "electromagnetic pollution" of these interference sources to the power supply, so as to ensure the stable operation of the system and improve the performance.
★ Support automatic fingerprint recognition.
